Specifications

• Product Code: EG25-G&KNe
• Architecture: ARM 32bit
• CPU: Cortex A7
• CPU Core Count: 1
• CPU Nominal Frequency: 800 MHz
• RouterOS License: Level 3
• Operating System: RouterOS v7
• RAM: 256 MB
• Storage Size: 256 MB
• Storage Type: NAND
• MTBF: Approximately 100,000 hours at 25°C
• Tested Ambient Temperature: -40°C to 70°C

Powering

• Number of DC Inputs: 2 (PoE-IN, USB-C)
• Maximum Power Consumption: 6 W
• PoE In: 802.3af/at
• Cooling Type: Passive
• PoE Input Voltage: 12–57 V
• USB-C Input Voltage: 5 V

Mobile

• 2G Category: Class12
• 2G Bands:
  • 2 (1900 MHz)
  • 3 (1800 MHz)
  • 5 (850 MHz)
  • 8 (900 MHz)
• 3G Category: R8 (42.2 Mbps Downlink, 5.76 Mbps Uplink)
• 3G Bands:
  • 1 (2100 MHz)
  • 2 (1900 MHz)
  • 4 (1700 MHz)
  • 5 (850 MHz)
  • 6 (850 MHz)
  • 8 (900 MHz)
  • 19 (800 MHz)
• LTE Category: 4 (150 Mbps Downlink, 50 Mbps Uplink)
• MIMO DL: 2×2
• MIMO UL: 1×1
• LTE FDD Bands:
  • 1 (2100 MHz)
  • 2 (1900 MHz)
  • 3 (1800 MHz)
  • 4 (1700 MHz)
  • 5 (850 MHz)
  • 7 (2600 MHz)
  • 8 (900 MHz)
  • 12 (700 MHz)
  • 13 (700 MHz)
  • 18 (800 MHz)
  • 19 (800 MHz)
  • 20 (800 MHz)
  • 25 (1900 MHz)
  • 26 (850 MHz)
  • 28 (700 MHz)
• LTE TDD Bands:
  • 38 (2600 MHz)
  • 39 (1900 MHz)
  • 40 (2300 MHz)
  • 41 (2500 MHz)
• TAC: 01673800

Ethernet

• 10/100/1000 Ethernet Ports: 1
• 1G Ethernet Port with Reverse PoE (PoE-in): 1

Peripherals

• SIM Slots: 1 Modem (Nano SIM)

Other

• CPU Temperature Monitor: Yes
• PCB Temperature Monitor: Yes
• Bluetooth Version: 5.4
• GPS RF Connector Type: SMA
• eSIM: Yes

Certification & Approvals

• Certifications: CE, FCC, IC, EAC, ROHS
• IP Rating: IP20
