UniFi Express 7
UniFi Express 7
Mesh-scalable, super-compact 10G Cloud Gateway
🔒 100% Secure & Encrypted Payments
⚡ Instant Service Activation
🚚 Fast & Reliable Delivery
💬 24/7 Expert Technical Support
✅ Trusted by Businesses Worldwide
🔄 Easy Returns
- Overview
- Dimensions: 117 x 117 x 42.5 mm (4.61 x 4.61 x 1.67")
- UniFi Application Suite
- Network: Yes
- Managed UniFi Devices: 30+
- Simultaneous Users Connected: 300+
- Ports
- Max WAN Port Count: 1
- Default WAN Ports: 1 x 10 GbE RJ45
- Port Layout: 1 x 2.5 GbE RJ45, 1 x 10 GbE RJ45
- Performance
- IDS/IPS Throughput: 2.3 Gbps
- Form Factor: Compact desktop
- Coverage Area: 160 m²
- Security
- Stateful Firewall: Yes
- Layer 7 Firewall: Yes
- DPI & Traffic Identification: Yes
- Zone-Based Firewall Filtering: Yes
- Content Filtering: Yes
- Intrusion Prevention (IPS/IDS): Yes
- Ad Blocking: Yes
- IDS/IPS Signatures: 20,000+
- VLAN/Subnet Segmentation: Yes
- VPN & SD-WAN
- SD-WAN: Yes
- Site-to-Site VPN: Yes
- IPsec: Yes
- OpenVPN: Yes
- WireGuard: Yes
- L2TP: Yes
- VPN Client (OpenVPN): Yes
- VPN Client (WireGuard): Yes
- Networking
- OSPF: Yes
- Advanced QoS: Yes
- mDNS: Yes
- Advanced NAT: Yes
- RADIUS Server: Yes
- RADIUS over TLS: Yes
- LTE Backup Failover: Yes
- Internet Quality Reporting: Yes
- Policy-based Routing: Yes
- Custom DHCP Server: Yes
- IPv6 Support: Yes
- IGMP Proxy: Yes
- Virtual Network Override: Yes
- Integrated WiFi
- WiFi Standard: WiFi 6 / 6E / WiFi 7
- Throughput: 6GHz - 5.7 Gbps, 5GHz - 4.3 Gbps, 2.4GHz - 688 Mbps
- MIMO: 2x2 (All bands)
- Antenna Gain: 6GHz - 6 dBi, 5GHz - 7 dBi, 2.4GHz - 4 dBi
- Max TX Power: 6GHz - 24 dBm, 5GHz - 26 dBm, 2.4GHz - 23 dBm
- Wireless Security: WPA/WPA2/WPA3
- Max BSSIDs: 4 per Radio
- Hardware
- Max Power Consumption: 22W
- Power Method: USB Type-C
- Heat Dissipation: 75 BTU/hr
- Processor: Quad-core ARM Cortex-A53
- RAM: 3 GB
- Weight: 422 g
- Enclosure: Polycarbonate
- Display: 0.96" status display
- Management
- Ethernet LED: Yes
- Reset Button: Yes
- Environment
- Operating Temperature: -10 to 40°C
- Humidity: 5–95%
- NDAA Compliant: Yes
- Software
- VLAN: 802.1Q
- Guest Traffic Isolation: Yes
- UniFi Network Required: Version 9.0.108+
Q: Is setup instant?
A: Yes.
