Designed for high-speed data, voice, and video transmission up to 1 Gbps across structured cabling networks.
Key Features
- Dual jacket layer: Offers extra protection for outdoor and industrial use
- 100% bare copper: Provides excellent conductivity with minimal signal loss
- Supports Gigabit Ethernet, PoE, and high-speed data transmissions
- Flame-retardant and weather-resistant jacket options available
- Ideal for long-distance structured cabling, CCTV systems, and data centers
Specifications
- Cable Type: CAT6 UTP (Unshielded Twisted Pair)
- Conductor Material: 100% Bare Copper
- Conductor Diameter: 0.57 mm ± 0.02 (23 AWG Solid)
- No. of Pairs / Conductors: 4 Pairs / 8 Conductors
- Insulation Material: High-Density Polyethylene (HDPE)
- Inner Jacket: PVC (Flame Retardant, LSZH Optional)
- Outer Jacket: HD PVC / LSZH (Optional)
- Jacket Color: Grey / Blue / Custom on Request
- Cable Length: 305 Meters (Standard Box)
- Bandwidth: Up to 250 MHz
- Data Transmission Speed: 10 / 100 / 1000 Mbps (Gigabit Ethernet)
- Compliance Standards: ANSI/TIA-568.2-D, ISO/IEC 11801, RoHS
- Fire Retardant Rating: IEC 60332-1
- Temperature Range: -20°C to +70°C
- Packaging: Wooden Reel / Pull Box
- Application: LAN, CCTV, IP Phones, PoE Devices, and Networking Infrastructure
