• Port 1 to port 4 compatible with IEEE802.3af/at standard power.
• Supply (Maximum power of each port is 15.4W).
• 4x 10/100 /1000Mbps automatic adjustment RJ45 ports.
• Meets the standards of the IEEE 802.3 /IEEE 802.3u/IEEE 802.3z and IEEE 802.3ab.
• Flow Control Type: Full duplex adopts IEEE 802.3x standard, half duplex adopts back pressure standard.
• Auto-flip ports (Auto MDI/MDIX).
• Network port has lighting-proof function (AC power port: differential mode +/-2kV, common mode +/-4kV).
• Maximum PoE Power: 65W.
• Store-and-forward architecture, 192K forwarding memory .
• All ports support wire-speed switching, frame size within the range of 64 to 1536 can achieve wire-speed.
• Wall-mounted design, easy to install and use.
• Automatic adjustment, plug and play, no need software and protocol conversion.

What This Product Does

Flexible:
Two High Speed Uplink Ports The built-in two Gigabit uplink ports provide fast connection to servers or the backplane of the gigabit speed. The effective connectivity of the four 10/100/1000Mbps ports, allows growing business networks, classrooms and workgroups to obtain benefits from the demand for superior performance and sustain network expansion. This high-performance switch features with non-blocking, wire-speed switching, and 8.8Gbps switching capacity. All RJ45 ports can auto adjust the highest connection speed for a normal working, Auto Uplink ™ technology can ensure proper network connection.

Application Situations:
•    Million HD surveillance transmission and power supply.
•    Wireless AP distribution transmission and power supply.
•    VoIP transmission, intelligent home systems.
•    City intelligent traffic monitoring system (ITS), safe city, and wireless city.
•    Highway surveillance system, electronic road surveillance, snapshot system.
•    Large industrial factory & enterprise security surveillance system,
network multifunction system.
